AC Adapter/Charger Carrying Case Hook Chisel Flat Head Notched Head Hanger Cone Head Thread Adapter Extension Rod USB cable Shimpo FGV-50XY 1000 Hz Sample Rate provides faster sampling producing better resolution and more accurate results High accuracy +/-0.2% F.S., ideal for strict tolerances Measure and record compression and tension tests- permits true “push-pull” testing 180° Reversible display and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand Maximum data collection flexibility with 3 outputs: USB, RS-232 & Analog Output Digital Force Gauge, 50 lb Capacity Digital Force Gauges with 180° reversible display & dual labeled keypad for both push, and pull applications. The Series FGV-XY DART 2.0 Force Gauges combine a rugged, ergonomic, and compact design to provide a complete force testing instrument. These instruments are utilized in a variety of applications such as incoming quality inspection, finished goods testing, R&D or almost any portable or force stand testing requirement. On-board statistical calculations provide fast access to maximum, minimum, average, and standard deviation data. Units include the free TORIEMON-USB software and USB cable allowing further data analysis on a PC. The 1,000-point memory allows for data exporting in real-time or after testing is complete. In addition, the RS-232C and analog outputs provide the DART 2.0 with maximum communication flexibility. Models are available from 0.5 lbs to 200 lb ranges providing a large offering for various testing requirements. The 180° reversible display combined with the adjustable force direction and dual labeled keypad enable the FGE-XY to excel in both compression and tension applications in any direction. Typical applications include wallboard, wire pull, wire crimps, trigger pull, brake pedal, aerospace ceramic, springs, food ripeness, corrugated paper strength, blister pack, medical component, muscle strength, ergonomic testing, adhesives, syringe plunger, needle sharpness and many more. Force / Torque / Hardness Meters/Force Meter Template Capacity 50 LBS Resolution (Force) 0.01 LBS Accuracy ±0.2% F.S. Manufacturer Specs Model FGV-50XY Capacity 50 lb 200 N 20 kg Resolution 0.01 lb 0.1 N 0.01 kg Units of Measure lb / kg / N Measurements Mode Standard, Compression Peak, Tension Peak Display Rate User Selectable: 1, 2, 3, 5, 10, 20 times per second Sampling Rate 1000 times per second Accuracy ± 0.2% F.S. Influence of temperature Gain : ± 0.01 LOAD / Zero : ±0.01 / R.C. / Drift of zero point can be cancelled with tracking function. Display Main display: 4-digits 12mm high, Reversible Units display: 3-digits 7mm high Other display: “LO BAT”(Low Battery Voltage), “BAT”(Battery Charging), “OVR”(Overload), “Peak”(Peak Hold) Overload 200% of Full Scale Tracking User Selectable (ON/OFF) Output USB Allows communication between FGV-XY and ToriemonUSB via USB cable(included). RS-232C Allows communication between the FGV-XY and RS-232C devices. RS-232C cable is an optional accessory. Analog ± 1V, Accuracy is ± 50mV through a 12 bit D/A. ZERO affects this output, and is updated at 1000 times/second. Load is >10kΩ Overload/Comparator Open-collector output (Max DC30V/5mA). Power Rechargeable Nickel hydride battery or AC adapter/charger. Usable while charging. Operating Time: Approximately 8 hours after a full charge. Charging Time: 16 Hours Max. Auto Power Off Default is 10 minutes. Can be disbaled. Automatically disabled when connected to AC adapter. Memory function Continuous memory: 1000 data points, Single memory: 100 data points, Standard memory: 50 data points Statistics functions (max, minimum, peak, average, standard deviation) Comparator Function User Selectable: HI and LO Temperature Range 0 ~ 40° C (-32 ~ 104° F) Humidity Range 35 ~ 85% RH Dimensions 147mm (L) x 75mm (W) x 38mm(H) Weight Approx. 450g Accessories (Included) AC adapter/charger, carrying case, hook, chisel, flat head, notched head, hanger, cone head, thread Adapter, extension rod, USB cable
